High-performance Tufting machines for flexible and technical carpets

Model:（MTC-MH, 3/16"GG high speed level cut pile）

1.Technical Description

The body housing is full cast frame, main mechanical drive parts all NSK and IKO bearings of Japan  brand, adopts 45# steel modulation polishing shaft

Gauage:3/16"GG

Pile:level cut pile

Effective width of tufting carpet is 4.2 m

Straight Moduel needle structure needle beam

"Pile height adjustable is very convenient and operator friendly. Operators need to release the Hydraulic pressure

by turning the button, loose the nuts a bit and by touch of a button can increase and decrease the bed plate by

motor. Hydraulic pressure of the bed plate is maintained and monitored by the PLC itself.with Hydraulic pressure to

run at High RPM.

Variable frequency adjustable motor

Adjustable stroke

Weight: About 12 tons

MACHINE POWER  45KW, 380VAC 3Phase 50Hz

Pile Height range: 10-50mm

Machine speed: 700-1000 RPM

Stitch Length: 20-60 stitch per 10cm

"1 set of Double servo backing control system,Separate and combined Jog Mode for fabric feeding motor, fabric

backward motor also for both yarn rollers separately. "

"Yarn Feeding (2 sets of Double rollers one driven by servo motor and another by respective gear) 3KW per

motor"

Start control cabinet, soft start/stop, High Parking, Fault indication, meter counter, Configure front pull switch, front photoelectric switch

(1pc of Yarn collecting plate)

Include 882pcs needles, hook, knife, forks according to 4.2m configuration.

( One set of control cabinet and software)

with 2*882 ends creel

with mending frame and winding unit
